Loomcore: a C++ runtime that schedules models as a graph

Timeline · One job

job-9 · Red fox · 39.2 ms

Recorded 1 Oct 2026

Recorded on 1 Oct 2026 on a local build of the same runtime (Intel Core i5-1145G7, Windows 11). Connecting to the live runtime.

Ctrl + wheel zooms, drag pans, ← → step through events.Tap a bar or marker for details; + and − zoom, then drag to pan. Open in Perfetto: copy the trace, save it as trace.json, drop it on ui.perfetto.dev.

All 4 events in time order

ms	track	what	detail
0.000	Jobs	job-9	completed after 39.0 ms
8.67	CPU	mobilenet FP32	13.1 ms · job-9
21.9	Router	Router decision	CompositeRouter: LatencyBudgetPolicy: remaining budget 18.2 ms < threshold 30.0 ms; downgrading to INT8 for node 'bert_tiny'
35.0	GPU_SIM	bert_tiny INT8	4.00 ms · job-9

Result

What the job produced

Recorded 1 Oct 2026

mobilenet says

red fox

77.5% confidence

red fox77.5%
dhole14.4%
kit fox4.3%
red wolf3.0%
grey fox0.2%

Per node
node	lane	precision	ms
`mobilenet`	CPU	FP32	13.1
`bert_tiny`	GPU_SIM	INT8	4.00
job	budget 40.0 ms		39.2

Router decisions

bert_tinyLatencyBudgetPolicyremaining budget 18.2 ms < threshold 30.0 ms; downgrading to INT8 for node 'bert_tiny'

bert_tiny embedding

Embedded a photo of a red fox. The first 16 of 128 values:

-1.000
0.027
-0.999
0.978
-1.000
0.765
-0.996
-0.540
0.055
0.022
-0.582
0.060
-0.013
1.000
-0.878
-0.574

Benchmark

FP32 vs INT8, measured

Recorded 1 Oct 2026

Intel Core i5-1145G7AVX2 presentAVX-512 presentAVX-512 VNNI presentAVX-VNNI absent

p50 latency per inference, milliseconds, single item, one thread per session
model	FP32 p50	INT8 p50	FP32 INT8	INT8 speed-up	on AMD Ryzen 9 6900HX
MobileNetV2 · static QDQ	10.4	9.98		1.04x	0.93x
bert_tiny · dynamic	0.536	0.450		1.19x	1.13x

This CPU has VNNI (int8 dot-product instructions), so ONNX Runtime's INT8 convolutions use them and INT8 MobileNetV2 is 1.04x as fast as FP32. The gain is modest: static QDQ quantization adds Quantize/Dequantize nodes, and at batch size 1 on one thread their cost eats into what VNNI saves.

Recorded machine: loomcore_bench, 20 warm-up and 100 measured runs per variant, 1 Oct 2026; ONNX Runtime 1.30, one intra-op thread per session (the scheduler supplies the parallelism). Latency only: the INT8 models are not checked for accuracy. Reference numbers from docs/BENCHMARKS.md.

Controls

Drive the runtime

Deadline

Budget per jobnone

Binding: admission control rejects a job that cannot fit, and the reaper cancels one that runs out of time.

Checking the live runtime…

Graph

mobilenet → bert_tiny

Recorded 1 Oct 2026

image · 224×224 RGB

mobilenetCPU

MobileNetV2 · image classifier

FP32INT8batch ≤ 4 · 8 ms window

confidence ≥ 0.85? skip bert_tiny

bert_tinyGPU_SIM

BERT-tiny · text encoder

FP32INT8batch ≤ 4 · 12 ms window

"a photo of a {label}" → 128-d embedding

Router chain

In order. A skip ends the chain; otherwise the first policy to set precision or lane wins. Changes apply to the next run, which hot-swaps the graph to the new router first.

1
circuit-breaker
CircuitBreakerPolicy(0.5, 4, 2000)
Reads the node's recent success and failure outcomes; skips a node whose error rate reached 50% over at least 4 runs; lets one probe through after 2 s.
2
bulkhead
BulkheadPolicy(6)
Reads how many requests for the node are in flight; sheds (skips) a request once 6 are already in flight for that node.
3
confidence-gate
ConfidenceGatePolicy(0.85)
Reads mobilenet's softmax confidence for this image; skips bert_tiny once mobilenet is at least 85% sure; there is nothing left to describe.
4
precision-planner
PlannedPrecisionPolicy()
Reads measured FP32 and INT8 p95 per node, and the job's budget; solves a 0/1 knapsack over the critical path for which nodes to run INT8 so the job fits.
5
latency-budget
LatencyBudgetPolicy(30)
Reads the job's remaining time budget; drops a node to INT8 once less than 30 ms of the budget is left.
6
load-aware
LoadAwareBackendPolicy()
Reads the CPU and GPU_SIM queue depths; sends the node to whichever lane has the shallower queue.

Scheduleradmission controldeadline cancellationprecision planningEDF lanes

Claims

Every claim, next to what checks it

From docs/CLAIMS.md. Each links to the test case or program that asserts it.

#	claim	checked by
1	The full test suite passes	`CMakeLists.txt`
2	A job's promise is settled exactly once, even under a deadline reaper racing a node's natural completion (no `std::terminate`)	`test_scheduler_deadlines.cpp:173`
3	Batching never mixes incompatible non-batch shapes for the same node	`test_scheduler_deadlines.cpp:80`
4	`Scheduler::shutdown()` actually stops accepting new jobs (not a no-op)	`test_scheduler_deadlines.cpp:119`
5	Admission control rejects a job the precision planner judges undeliverable, and dispatches nothing first	`test_scheduler_deadlines.cpp:136`
6	The precision-downgrade knapsack finds the true minimum-quality-loss set, which a savings-only greedy would not	`test_planner.cpp:73`
7	The circuit breaker lets through exactly one probe after cooldown, never more, under concurrent load	`test_router.cpp:223`
8	`Runtime::reloadGraph` hot-swaps the graph under continuous concurrent load with zero jobs lost	`test_runtime_reload.cpp:48`
9	The same hot-swap holds against the real mobilenet+bert_tiny pipeline, with per-swap timing reported	`examples/reload_demo.cpp`
10	The reference pipeline runs end to end (real image → classification → confidence-gated embedding) and reports real per-node p50/p95	`examples/run_example.cpp`
11	INT8 MobileNetV2 is measurably slower than FP32 on the reference (non-VNNI) machine — not fabricated, not silently skipped	`benchmarks/latency_bench.cpp`
12	The ORT dependency is fully encapsulated: the benchmark links and runs with no ONNX Runtime include/link dependency of its own	`benchmarks/latency_bench.cpp`
13	The C API is a real, separate consumable surface: a pure-C translation unit links and runs against it with no C++ Loomcore headers	`bindings/c/smoke_test.c`
14	The installed package is consumable via plain `find_package(Loomcore)` — not just "it builds in-tree"	`examples/consumer`
15	CI builds and tests both platforms (Windows + Linux) on every push/PR	`.github/workflows/build.yml`
16	A run's JSON-lines log converts to a real, structurally valid Perfetto/Chrome Trace Event Format timeline — lane tracks, per-execution duration bars, routing markers, DAG flow arrows	`test_perfetto_export.cpp`
